| G.652 | G.655 | 50/125μm | 62,5/125μm | ||
| Attenuazione (+20℃） |
850 nm | ≤3,0 dB/km | ≤3,0 dB/km | ||
| 1300 nm | ≤1,0 dB/km | ≤1,0 dB/km | |||
| 1310 nm | ≤0,36 dB/km | ≤0,40 dB/km | |||
| 1550 nm | ≤0,22 dB/km | ≤0,23 dB/km | |||
| Larghezza di banda (Classe A) | 850 nm | ≥500MHZ·km | ≥500MHZ·km | ||
| 1300 nm | ≥1000MHZ·km | ≥600MHZ·km | |||
| Apertura numerica | 0,200±0,015NA | 0,275±0,015NA | |||
Lunghezza d'onda di taglio del cavo |
≤1260 nm | ≤1480 nm | |||
| Tipo di cavo | Conteggio delle fibre | Conteggio provette sciolte T |
Conteggio riempitivo s |
Diametro cavo mm |
Peso del cavo kg/km |
Resistenza alla trazione Lungo/breve termine N |
Resistenza allo schiacciamento Lungo/breve termine N/100m |
Raggio di curvatura statico/dinamico mm |
| GYTY53-2~6 | 2-6 | 1 | 4 | 12.5 | 160 | 1000/3000 | 1000/3000 | 15D/30D |
| GYTY53-8~12 | 8-12 | 2 | 3 | 12.5 | 160 | 1000/3000 | 1000/3000 | 15D/30D |
| GYTY53-14~18 | 14-18 | 3 | 2 | 12.5 | 160 | 1000/3000 | 1000/3000 | 15D/30D |
| GYTY53-20~24 | 20-24 | 4 | 1 | 12.5 | 160 | 1000/3000 | 1000/3000 | 15D/30D |
| GYTY53-26~30 | 26-30 | 5 | 0 | 12.5 | 160 | 1000/3000 | 1000/3000 | 15D/30D |
| GYTY53-32~36 | 32-36 | 5 | 0 | 12.5 | 160 | 1000/3000 | 1000/3000 | 15D/30D |
| GYTY53-38~48 | 38-48 | 5 | 0 | 12.5 | 160 | 1000/3000 | 1000/3000 | 15D/30D |
| GYTY53-50~60 | 50-60 | 5 | 0 | 12.5 | 160 | 1000/3000 | 1000/3000 | 15D/30D |
| GYTY53-62~72 | 62-72 | 6 | 0 | 13.2 | 200 | 1000/3000 | 1000/3000 | 15D/30D |
| GYTY53-74~84 | 74-84 | 7 | 1 | 15.0 | 240 | 1000/3000 | 1000/3000 | 15D/30D |
| GYTY53-86~96 | 86-96 | 8 | 0 | 15.0 | 240 | 1000/3000 | 1000/3000 | 15D/30D |
| GYTY53-98~108 | 98-108 | 9 | 1 | 16.0 | 280 | 1000/3000 | 1000/3000 | 15D/30D |
| GYTY53-110~120 | 110-120 | 10 | 0 | 16.0 | 280 | 1000/3000 | 1000/3000 | 15D/30D |
| GYTY53-122~132 | 122-132 | 11 | 1 | 18.0 | 290 | 1000/3000 | 1000/3000 | 15D/30D |
| GYTY53-130~144 | 134-144 | 12 | 0 | 18.0 | 290 | 1000/3000 | 1000/3000 | 15D/30D |
| GYTY53-146~216 | 134-144 | 18 | 0 | 18.0 | 290 | 1000/3000 | 1000/3000 | 15D/30D |
